| Model | DINO-750F | DINO-1100F | DINO-1500F | DINO-1900F | DINO-4000F |
| Dimensions | 635 (W) X 300 (D) X 400 (H) mm | 1010(L) X 400 (D) X700 (H) mm | |||
| Weight | Approx. 25Kg | Approx. 30Kg | Approx. 35Kg | Approx. 55Kg | Approx. 65Kg |
| Inlet/Outlet connector | 13mm (1/2”) /13mm (1/2”) Dia | 19mm(3/4”) /19 mm (3/4”) Dia | 25mm(1”) /19 mm (3/4”) Dia | 25mm(1”) /25 mm (1”) Dia | 32mm(11/4”) /25 mm (1”) Dia |
| Power consumption | 1hp (0.75KW) | 1.5hp (1.1KW) | 2.0hp (1.5KW) | 2.5hp (1.7KW) | 5.0hp (4.0KW) |
| Principle of Bubble Generation | Pressurized Dissolutions Method (PDM) | ||||
| Water temperature | 5 to 60 deg C | ||||
| Bubble Size | 50nm – 250nm (80%) | ||||
| Water type | Fresh n Marine | Fresh n Marine | Fresh Water n Marine | Fresh Water / Marine water | Fresh Water n Marine |
| Auto Backwash | Yes | Auto BackWash With Self recovery | Yes | Auto BackWash w/Self Recovery | Auto BackWash With Self recovery |
| Output* | 1.0 m3/hr | 2.0 m3/hr | 3.8 m3/hr | 4.0 m3/hr | 8.0 to 10 m3/hr |
| Gas Type | Air/Oxygen/Ozone | ||||
| Material Body | SS304 & SS316 | ||||
| Power Supply | Single phase* 220V*50HZ | 3 phase* 415V*50HZ | |||
|
1g/hr quartz tube ozone generator with 12 volt car lighter socket is suitable for disinfection of interior of a car, remove all pollutants and odors.
|
The High-Efficiency Air-Cooled Ozone Generator is an ideal solution for applications without cooling water availability.
|
UV sterilizers use the 304SS# stainless steel inside and outside, the main body internal and external are polished to enhance the UV irradiance. Assembling with the high purity quartz tube, matching with the appropriation uv lamp tube for water treatment, sterilization strong, long lifetime, stable and reliable operation, bactericidal efficiency is more than 99.99%.
|
UV sterilizers use the 304SS# stainless steel inside and outside, the main body internal and external are polished to enhance the UV irradiance. Assembling with the high purity quartz tube, matching with the appropriation uv lamp tube for water treatment, sterilization strong, long lifetime, stable and reliable operation, bactericidal efficiency is more than 99.99%.
|
UV sterilizers use the 304SS# stainless steel inside and outside, the main body internal and external are polished to enhance the UV irradiance. Assembling with the high purity quartz tube, matching with the appropriation uv lamp tube for water treatment, sterilization strong, long lifetime, stable and reliable operation, bactericidal efficiency is more than 99.99%.
